SPECIFICATION
| VEHICLE SPECIFICATION | DESCRIPTION |
| Truck Model | ZZ3257S3647W |
| Truck Brand | SINOTRUK—HOWO |
| Driving Position | Left hand Driving |
| Fuel tanker capacity（L） | 300 |
| The Total Mass | 35,000kg |
| Cargo box | 5600x2300x 1500 mm |
| Box thickness | Boot 8mm side 6mm |
| Dead Weight | 12300kg |
| Hydraulic Jack | Mid Lift |
| Max speed（km/h）(km/h) | 102 |
| Color | Optional |
| Chassis & Add Components | |
|
Frame Details |
High-Strength U-profile ladder frame with section of 300*90*8mm and reinforced sudfram, all cold riveted cross members. |
|
Dimension(Lx W xH)（ mm） |
8685x2496x3850 |
| Overhang(front/rear) (mm) | 1500/725 |
| Wheel base (mm) | 3625+ 1350 |
| Engine | |
| Model | WD615.47 |
| Power | 371hp/273kw.2000r/min |
| Emission | EURO II |
| Displacement(L) | 9.896 |
| Type | water-cooled，four strokes，6 cylinders in line，turbocharged, directly injection |
| Kind of Fuel | Diesel |
| Fuel Consumption(L/100km) | 25L/100km |
| Clutch & Gear Box System | |
| Clutch | SINOTRUKΦ430mm diaphragm spring clutch |
| Gear Box | HW19710 |
| Axles | |
| Front Axle Model | VGD95 axle. Capacity: 9000kg |
| Rear Axle | HC16 axle. Capacity:2X 16000kg |
| Ratio of rear axle | 4.8 |
| Electrical System | |
| Battery | 2X 12V/165A h |
| Alternator | 28V-1500kw |
| Starter | 7.5Kw/24V |
| Brake System | |
| Service brake | Dual circuit compressed air brake |
| Parking brake | spring energy, compressed air operating on rear wheels |
| Auxiliary brake | Engine exhaust brake |
| Steering system | |
| Model | ZF8118 |
| Type | hydraulic steering with power assistance |
| Wheels & Tyres | |
| Type | 1200R20 |
| Material | Steel tires |
| Quantity | 10+1 spare |
| Kin pin | 50mm or 90mm |
| Cabin | |
| Type | HW76 Standard cabin |
| single sleeper with air conditioner, all-steel forward control,55ºhydraulically tiltable to the front,2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers | |
